Recording
- Video CompressionH.264+/H.264
- Encoding Resolution
When 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF
When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF
Frame Rate
- Main stream:
When 1080p Lite mode not enabled:
For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
When 1080p Lite mode enabled:
1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
2CIF@6fps; CIF/QVGA/QCIF@ 25fps (P)/30fps (N)
Video And Audio
- IP Video Input: Up to 4-ch Up to 960p resolution Support H.264+/H.264 IP cameras
- Analog Video Input: 4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- Turbo HD Input: 1080p25, 1080p30, 720p25, 720p30
- AHD Input: 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input: 1080p25, 1080p30, 720p25, 720p30
- CVBS Input: Support
- Audio Input: 1-ch, RCA (2.0 Vp-p, 1 KΩ)
- Audio Output: 1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio: Reuse the first audio input
- Synchronous Playback: 4-ch
- VGA/HDMI Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Network
- Remote Connections: 32
- Network Protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
- Network Interface: 1, RJ45 10M/100M self-adaptive Ethernet interface
Auxiliary Interface
- SATA: SATA
- Capacity: Up to 6 TB capacity for each disk
- Alarm In/Out: N/A
- USB Interface: Rear panel: 2 × USB 2.0
General
- Power Supply: 12 VDC
- Consumption (Without HDD): ≤ 8 W
- Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity: 10% to 90%
- Dimensions: (W × D × H)200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
- Weights (Without HDD): ≤ 0.8 kg (1.8 lb)
